Hikvision AI-SCD285 8MP Akıllı Dome IP Kamera
AI Supported 8MP, H265/H264, IP67 Certified, SSL Secure, up to 60m IR Dome Camera
Key Features
● 1/3" Progressive Scan CMOS
● Color: 0.018 Lux @(F1.6, AGC ON), 0.028 Lux @(F2.0, AGC ON)
● 2.8 mm/4 mm/6 mm fixed lens
● H.265+, H.265, H.264+, H.264
● Three streams
● 120 dB WDR (Wide Dynamic Range)
● IR range: up to 30 m
● BLC/3D DNR/ROI/HLC
● IP67, IK10
● 3-Axis adjustment
Specifications
Camera
Image Sensor: 1/3″ Progressive Scan CMOS
Min. Illumination: Color: 0.018 Lux @ (F1.6, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
Shutter Speed: 1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120 dB
Day & Night:
ICR Cut
Angle Adjustment:
Pan: 0° to 355°, tilt: 0° to 75° Lens
Lens Type & FOV:
2.8 mm, horizontal FOV 98°, vertical FOV 53°, diagonal FOV 115°
4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 88°
6 mm, horizontal FOV 49°, vertical FOV 26°, diagonal FOV 57°
Aperture:
2.8 mm: F2.0; 4 mm: F2.0; 6 mm: F1.6
Lens Mount M12 Illuminator IR Range:
30 m
Wavelength:
850 nm
Smart Supplement Light:
Yes
Video Max. Resolution:
2560 × 1440
Main Stream:
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream:
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream:
50Hz: 1fps (1280 × 720, 640 × 360)
60Hz: 1fps (1280 × 720, 640 × 360)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
Video Bit Rate:
32 Kbps to 8 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Stream Type:
Main stream/Sub-stream/Third stream
Scalable Video Coding (SVC):
H.265 and H.264 support
Region of Interest (ROI):
1 fixed region for main stream and sub-stream
* Note: The frame rate of the sub-stream cannot exceed the maximum frame rate of the current main stream. Network
Simultaneous Live View:
Up to 6 channels
API
ONVIF (PROFILE S), ISAPI, SDK
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
User/Host
Up to 32 users. 3 user levels: administrator, operator and user
